Centrifuge

Low-Speed Refrigerated Centrifuge

CF-FLR5-I

More info

Features:
1. Advanced Control System, Excellent separation
1) Ten kinds of Accel/Decel modes can be selected or directly set up the time of Accel/Decel; User can set up the operate parameter by themselves, to achieve the best centrifugal result.
2) Short running function, easy to diversification centrifugation.
3) Proprietary SCT speed control technical, high efficiency.
4) Proprietary SBT soft brake control technical, to avoid mix up and ensure get maximum specimen.
2. High Safety, Ease of use
1) Automatic rotor identification system, no need to select rotor number.
2) Over temperature, over speed, door and unbalanced protection.
3) Steel body, Stainless steel chamber, Steel Protective sleeve.
4) Can take the rotor with aerosol-tight lid for use with hazardous samples.

3. Friendly Display, Humanity Operate
1) LCD, LED multiple-screen display, the Program, Accel/Decel modes, RPM/RCF, Time, Temperature are all easy to set up without any key combination.
2) Microprocessor control, operated data can be saved automatically, can start the instrument with RCF directly, can be store and use 40 kinds of self-defining operating modes directly by user-self.

4. Good parts, Reliable and longlasting
1) Brushless motor which has high torque, "SKF" supper speed bearing, Freon-free compressor from Europe.
2) Aerospace rubber for damping, super duralumin alloy from Aluminum Corporation of China Limited (CHALCO).
TECHNICAL PARAMETER

Model

CF-FLR5-I

Max Speed

5500r/min

Max Rcf

5310×g

Max Capacity

3000ml

Speed Accuracy

±50r/min

Temperature Range

-20°C-+40°C

Temperature Accuracy

±1°C

Time Range

1-999min

Power Supply

AC 220V 50Hz 20A

Noise

≤65dB

Dimension

615×780×900mm

Weight

190kg

Rotor


Rotor Type

Number

Capacity

Max Speed  (r/min)

Max RCF(×g)

Dimension of tube  (mm)

Angle Rotor

No.1

12×10ml

5000 r/min

3500×g

Φ16×81

Swing Rotor

No.2

4×100ml

5500 r/min

5310×g

Φ38×124

No.3

4×500 ml

4000 r/min

3580×g

Φ80×140

No.4

4×250ml

4000 r/min

3500×g

Φ64×112

No.5

148×7ml

4000 r/min

3200×g

Φ13×78

No.6

72×5ml

4000 r/min

2830×g

Φ14×54

No.7

32×15ml

4000 r/min

2810×g

Φ16×114-118

No.8

8×50ml

4000 r/min

2810×g

Φ28×105-115

No.9

96×7ml

4000 r/min

2800×g

Φ13×78

Microplate Rotor

No.10

2×2×96 holes

4000 r/min

2300×g

Microplate Rotor
