More info
1. Features
Performance reliability: overall composite rotor, high strength, stable performance;
Easy to use: water, electricity, gas interface connection simple and convenient, customers can choose air or water cooled depending on the usage environment and conditions ;
Wide application: for mass spectrometry, surface physics, coating, ion etching, physics and other fields;
2. Technical Index
Product Model | MP-160/700 | |
Air inlet flange | DN160LF | DN160CF |
Pumping speed L / S (air) | 700 | |
Compression ratio N2 | ＞109 | |
Ultimate pressure (Pa) | 6×10-7 | 6×10-8 |
Exhaust port flange | KF40 | |
Using a bearing | Ceramic grease lubricated bearings | |
Start Time (min) | ＜4 | |
Rated operating number of revolutions (rpm) | 36000 | |
Recommended to use Pre stage pump L / S | 4-8 | |
Cooling mode and water temperature | Water-cooled，≤25℃ | |
Mounting | Any angle | |
Pump baking temperature (℃) | ＜120 | |
Ambient Temperature (℃) | 5～40 | |
Weight (kg) | 19 | |
